Page 1 as PDF
Three Dimensional Geometry in one look
a line needs a direction and a point, a plane needs a normal and a distance
Direction cosines vs direction ratios
- cosines of the angles the line makes with the x, y, z axes
- always satisfy l^2+m^2+n^2=1
- unique for a given directed line, reversing the direction flips every sign
- any numbers proportional to l, m, n
- not unique: (2,4,6) and (1,2,3) describe the same direction
- recovered as l = a/√a^2+b^2+c^2, and likewise for m and n
Equation of a line
- vector form, through a point a, direction b
r = a + lambdab - cartesian form, through (x_1,y_1,z_1), direction ratios a,b,c
x-x_1/a = y-y_1/b = z-z_1/c - through two points
x-x_1/x_2-x_1 = y-y_1/y_2-y_1 = z-z_1/z_2-z_1
Angle between two lines
- direction ratios (a_1,b_1,c_1) and (a_2,b_2,c_2)
cosθ = frac|a_1a_2+b_1b_2+c_1c_2|√a_1^2+b_1^2+c_1^2√a_2^2+b_2^2+c_2^2 - perpendicular exactly when
a_1a_2+b_1b_2+c_1c_2 = 0 - parallel exactly when
a_1/a_2 = b_1/b_2 = c_1/c_2
Page 1 of 3. The full sheet, all 3 pages, opens free in the app.
What this Three Dimensional Geometry sheet covers
- Direction cosines vs direction ratios
- Direction cosines (l, m, n)
- Direction ratios (a, b, c)
- Equation of a line
- vector form, through a point a, direction b
- cartesian form, through (x_1,y_1,z_1), direction ratios a,b,c
- through two points
- Angle between two lines
- direction ratios (a_1,b_1,c_1) and (a_2,b_2,c_2)
- perpendicular exactly when
- parallel exactly when
- Two lines, three possible relationships
- Equation of a plane
- normal form, unit normal n-cap, distance d from the origin
- cartesian normal form, l,m,n direction cosines of the normal
- through a point, normal direction ratios a,b,c
- intercept form, axis intercepts a,b,c
- Angle between planes, and between a line and a plane
- between two planes, normals N1 and N2
- perpendicular planes
- between a line (direction b) and a plane (normal N)
- Shortest distance between two skew lines
- Classifying two lines in space
- Distance formulas at a glance
- Things to remember before the traps
- Traps that cost marks
- Tricks that save time
