Page 1 as PDF
Mechanical Properties of Fluids in one look
pressure pushes everywhere at once, and a narrower pipe always means faster and lower
Pressure in a fluid
- pressure is force per unit area, acting normal to the surface
- a scalar: it has no direction of its own
- at a point in a fluid at rest it is the same in every direction
- it grows with depth, and one level of a connected fluid has one pressure
Pressure and depth
- definition, SI unit the pascal
P = F/A,quad 1 Pa = 1 N/m^2 - absolute pressure at depth h
P = P_a + ρ g h - gauge pressure
P - P_a = ρ g h - between two depths
Δ P = ρ g (h_2 - h_1)
Measuring pressure
- mercury barometer: P_a = ρ g h of the standing column
- its height ignores the tube's tilt and width
- open tube manometer: h gives the gauge pressure
- 1 atm = 1.013×10^5 Pa = 76 cm of mercury; 1 torr = 1 mm of mercury
Page 1 of 7. The full sheet, all 7 pages, opens free in the app.
What this Mechanical Properties of Fluids sheet covers
- Pressure in a fluid
- Pressure and depth
- definition, SI unit the pascal
- absolute pressure at depth h
- gauge pressure
- between two depths
- Depth, shape, piston
- Measuring pressure
- Barometer, manometer, gauge
- The hydraulic lift
- one pressure at both pistons
- force at the wide piston
- the same oil moves, so
- Lift and brake
- Archimedes' principle
- Upthrust and floating
- upthrust, fluid density σ, volume under V
- apparent weight
- floating at rest
- share of the body under the surface
- Weighing and floating
- Streamline flow
- Equation of continuity
- mass in equals mass out
- incompressible fluid
- in one line
- Turbulent flow
- Streamlines, continuity, turbulence
- Bernoulli's principle
- along one streamline, ideal fluid
- horizontal pipe, h fixed
- fluid at rest, v = 0
- Along a pipe, the Venturi meter, Torricelli
- Viscosity
- Newton's law of viscosity
- force on a layer of area A
- two plates, gap l, relative speed v
- SI unit of the coefficient η
- going further: flow through a pipe, pressure drop Δ P over length l
- Layers, pipe, temperature
- Stokes' law and terminal velocity
- drag on a small sphere
- at terminal velocity
- terminal velocity, sphere ρ in a fluid σ
- Terminal velocity at the limits
- Falling ball
- Surface tension
- Surface tension and surface energy
- force per length along the surface
- a film has two surfaces
- work to make new surface
- units
- Molecules, film, energy
- Angle of contact
- the three tensions balance at the edge
- so the angle comes from
- Acute and obtuse contact angle
- Acute (wets)
- Obtuse (non-wetting)
- Water, mercury, detergent
- Excess pressure in a drop and a bubble
- inside a liquid drop, one surface
- inside a soap bubble, two surfaces
- an air bubble inside a liquid
- Capillary rise
- rise or fall in a fine tube of radius r
- the surface's pull balances the column's weight
- Rise, fall, radius
- Traps that cost marks
- Tricks that save time
