Work, Energy and Power in one look
work loads energy in, power says how fast, collisions decide what is left after
Work, defined properly
- work needs a force and a displacement along it
- only the part of F along the motion does work
- across the motion: none. work is a scalar: +, − or 0
- lifting: you +, gravity −. pushing: you +, friction −
Work, the numbers
- a constant force, angle θ to the displacement
W = Fcdotd = Fdcosθ - the part of F that works
F_∥ = Fcosθ - you lift a body a height h, steadily
W_you = +mgh - gravity, over that same lift
W_g = -mgh
Kinetic energy and the theorem
- kinetic energy
K = 1/2mv^2 = p^2/2m - net work equals the change
W_net = Δ K = K_f - K_i - braking with a steady force f over d
-fd = 0 - 1/2mv^2
The work-energy theorem
- the net work on a body is the change in its kinetic energy
- it holds for any force, constant or changing, on any path
- add the work of every force: the net force sets the change
Page 1 of 7. The full sheet, all 7 pages, opens free in the app.
What this Work, Energy and Power sheet covers
- Work, defined properly
- Work, the numbers
- a constant force, angle θ to the displacement
- the part of F that works
- you lift a body a height h, steadily
- gravity, over that same lift
- Kinetic energy and the theorem
- kinetic energy
- net work equals the change
- braking with a steady force f over d
- The work-energy theorem
- A force that changes: the area is the work
- Conservative and non-conservative forces
- Variable force, spring
- work of a changing force
- the spring's restoring force
- work to stretch it by x, from rest
- block and spring, no friction
- Potential energy and bookkeeping
- near the ground, height h
- the conservative force does the work
- the force from the slope of U
- with heat Q lost
- a drop of height h from rest
- Conservation of mechanical energy
- Round a vertical circle
- Vertical circle at a glance
- The energy of a spring
- Equilibrium, read from U(x)
- Power: how fast the work is done
- What each collision keeps
- Collisions in one dimension
- momentum, always
- the coefficient of restitution
- first body after
- second body after
- Named special cases
- Collisions in two dimensions
- Where collisions are used
- Traps that cost marks
- Tricks that save time
