Straight Lines in one look
one slope, four forms, and the general equation that ties them together
Angle of inclination and slope
- the angle of inclination θ of a line is measured from the positive x-axis, counter-clockwise, with 0°≤θ<180°
- slope m=tanθ, defined for every θ except 90°
- θ=0° gives a horizontal line, m=0; θ=90° gives a vertical line, where slope is undefined
- a line rising left to right has 0°<θ<90°, so m>0; a line falling left to right has 90°<θ<180°, so m<0
Slope from two points, and the two big conditions
- slope through (x_1,y_1) and (x_2,y_2), x_1≠ x_2
m=y_2-y_1/x_2-x_1 - two lines are parallel exactly when
m_1=m_2 - two lines are perpendicular exactly when
m_1m_2=-1
Four special lines
- Horizontal line: θ=0°, m=0, equation y=k for some constant k
- Vertical line: θ=90°, slope undefined, equation x=k for some constant k
- Through the origin: y-intercept is 0, equation reduces to y=mx
- At 45° to the x-axis: θ=45°, so m=tan45°=1
Point-slope and two-point forms
- line through (x_1,y_1) with slope m
y-y_1=m(x-x_1) - line through (x_1,y_1) and (x_2,y_2), x_1≠ x_2
y-y_1=y_2-y_1/x_2-x_1(x-x_1)
Page 1 of 4. The full sheet, all 4 pages, opens free in the app.
What this Straight Lines sheet covers
- Angle of inclination and slope
- Slope from two points, and the two big conditions
- slope through (x_1,y_1) and (x_2,y_2), x_1≠ x_2
- two lines are parallel exactly when
- two lines are perpendicular exactly when
- Four special lines
- Horizontal line
- Vertical line
- Through the origin
- At 45° to the x-axis
- Point-slope and two-point forms
- line through (x_1,y_1) with slope m
- line through (x_1,y_1) and (x_2,y_2), x_1≠ x_2
- Slope-intercept, intercept and normal forms
- slope m, y-intercept c
- x-intercept a, y-intercept b, both nonzero
- perpendicular distance p from the origin, at angle ω to the x-axis, p>0
- Which form fits what's given
- The general equation
- Angle between two lines
- slope form, whenever 1+m_1m_2≠0
- general form, perpendicular exactly when
- Worked: equation of a line, then its distance from the origin
- Distance formulas
- perpendicular distance of (x_1,y_1) from Ax+By+C=0
- distance between two parallel lines Ax+By+C_1=0 and Ax+By+C_2=0
- Symbols
- Traps that cost marks
- Tricks that save time
