Mensuration in one look
surface area and volume of the standard solids, and what happens when they are combined or melted down
Two different questions the words are asking
- volume is the space filled inside a solid, measured in cubic units such as cm³ or m³
- surface area is the skin of the solid, measured in square units such as cm² or m²
- curved surface area counts only the rounded part, leaving out any flat circular ends
- total surface area counts the curved part plus every flat face the solid actually has
- the words in the question decide which: painting or covering wants area, while filling, holding or melting wants volume
- a solid open at the top, such as a bucket or a pipe, does not include that face in its total surface area
Cylinder, cone and sphere
- cylinder, curved surface then total
2π rh,quad 2π r(h + r) - cylinder, volume
V = π r^2 h - cone, curved surface then total
π rl,quad π r(l + r) - cone, volume, one third of the cylinder
V = 1/3π r^2 h - sphere, surface area then volume
4π r^2,quad 4/3π r^3 - hemisphere, curved then total, then volume
2π r^2,quad 3π r^2,quad 2/3π r^3
The slant height, which the cone formulas need
- a cone has three lengths: the radius r, the vertical height h and the slant height l
- they form a right angled triangle, so l^2 = r^2 + h^2
- the area formulas use l, while the volume formula uses h, and that is the distinction most often missed
- a question that gives r and h and asks for surface area wants the Pythagoras step first
- a question that gives r and l and asks for volume needs h recovered as h = √l^2 - r^2
Page 1 of 4. The full sheet, all 4 pages, opens free in the app.
What this Mensuration sheet covers
- Surface area
- Volume
- Two different questions the words are asking
- Cylinder, cone and sphere
- cylinder, curved surface then total
- cylinder, volume
- cone, curved surface then total
- cone, volume, one third of the cylinder
- sphere, surface area then volume
- hemisphere, curved then total, then volume
- The slant height, which the cone formulas need
- A cone needing the slant height first
- Conversion of solids
- Melting and recasting
- Melting, recasting and pouring
- A melting problem end to end
- Combined solids, and which faces disappear
- Area of a sector
- Length of an arc
- The sector and the arc
- Which formula the wording is asking for
- Traps that cost marks
- Tricks that save time
