Page 1 as PDF
Circle in one look
chords and arcs, the perpendicular from the centre, and the circle through three points
The parts of a circle
- a circle is the set of all points at a fixed distance, the radius, from a fixed point, the centre
- a chord joins any two points of the circle, and the longest chord is the diameter, which passes through the centre
- an arc is a piece of the circle itself, the minor arc being the shorter of the two a chord cuts off and the major arc the longer
- a segment is the region between a chord and its arc, while a sector is the region between two radii and their arc
- so a segment is cut off by a chord and a sector by two radii, which is the distinction most often confused
- concentric circles share a centre but have different radii
The chord theorems
- the perpendicular drawn from the centre to a chord bisects the chord, and this is the workhorse of the chapter
- the converse is also true: the line from the centre to the midpoint of a chord is perpendicular to it
- equal chords are equidistant from the centre, and chords equidistant from the centre are equal
- so the longer the chord, the closer it lies to the centre, and the diameter passes through the centre itself
- equal chords subtend equal angles at the centre, and the converse holds
- equal chords also cut off equal arcs, and equal arcs subtend equal angles at the centre
Why the perpendicular bisects the chord
- let AB be a chord of a circle with centre O, and let OM be perpendicular to AB
- join OA and OB, which are both radii
- compare △OMA and △OMB
- OA = OB, both being radii of the same circle
- ∠OMA = ∠OMB = 90°, since OM is perpendicular to AB, and OM = OM is common
- so by the RHS test the two triangles are congruent, and therefore AM = MB by corresponding parts
