Page 1 as PDF
Co-ordinate Geometry in one look
naming a point by two numbers, the quadrants, and the lines parallel to the axes
Building the plane
- two perpendicular number lines are drawn, the horizontal X axis and the vertical Y axis
- they meet at the origin, the point O with co-ordinates (0, 0)
- a point is named by an ordered pair (x, y), and the order is what makes (3, 5) different from (5, 3)
- x is called the abscissa, measured from the Y axis, and y the ordinate, measured from the X axis
- each is carried with its sign, positive to the right and upward, negative to the left and downward
- the two axes together are called the co-ordinate axes, and the plane they set up is the Cartesian plane
Signs in the four quadrants
| Quadrant | x | y |
|---|---|---|
| First | + | + |
| Second | - | + |
| Third | - | - |
| Fourth | + | - |
Points on the axes themselves
- a point on the X axis has ordinate zero, so it looks like (a, 0)
- a point on the Y axis has abscissa zero, so it looks like (0, b)
- the origin (0, 0) lies on both axes at once
- a point on an axis belongs to no quadrant, since the quadrants are the open regions between the axes
- so the answer to which quadrant does (4, 0) lie in is none, it lies on the X axis
- these conditions are how a question turns lies on the Y axis into the equation x = 0
Plotting and reading points
- to plot (a, b), move a units along the X axis first, then b units parallel to the Y axis
- the order is fixed: across before up, and reversing it plots a different point
- choose a scale that fits every point on the page, and mark the same scale on both axes unless there is a reason not to
- label each plotted point with its name and co-ordinates
- to read a point off, drop perpendiculars to both axes and read the two values with their signs
- a rough plot is worth doing even when the question is purely algebraic, since it catches sign errors instantly
Page 1 of 3. The full sheet, all 3 pages, opens free in the app.
