Page 1 as PDF
Constructions of Triangles in one look
compass and straight edge, four standard cases, and the condition that decides whether a triangle exists
The rules, and what must be shown
- only a compass and an ungraduated straight edge may be used to build the figure
- the ruler may be used to set the compass to a given length, but not to mark a point by measuring along a line
- a protractor is not allowed, so every angle must be built from arcs
- all construction arcs must be left showing, since they are the evidence the figure was constructed rather than drawn
- label each point as it is created, and write the steps beside the figure
- a rough sketch of the finished triangle drawn first tells you what you are aiming at and costs almost nothing
The four standard cases
- SSS: three sides given. Draw the longest as the base, then swing an arc of each remaining length from an end. Where the arcs cross is the third vertex
- SAS: two sides and the included angle. Draw one side, construct the angle at one end, cut off the second side along that arm, then join
- ASA: two angles and the included side. Draw the side, construct one angle at each end, and the two arms meet at the third vertex
- RHS: a right angle, the hypotenuse and one side. Draw the known side, erect the perpendicular at one end, then cut the hypotenuse off with an arc from the far end
