A 4-page visual revision sheet for Propositional Logic and Hardware Implementation, written for Class 11 ISC Computer Science. Formulas, diagrams and the traps that cost marks, laid out to be read the night before rather than the term before. Free, and it opens inside CapCompass.

Propositional Logic and Hardware Implementation revision notes, page 1 of 4 — A preview of page 1 — all 4 pages open full size in the app.

Propositional Logic and Hardware Implementation in one look

from a sentence that is true or false, to the gates that add two numbers

A proposition is a sentence with a truth value

a propositional variable stands for a statement that is either true or false, never both and never neither
connectives build bigger statements: NOT for negation, AND for conjunction, OR for disjunction, then implication and equivalence
a well formed formula is one built by the rules: variables are wff, and if p and q are wff then so are NOT p, p AND q, p OR q and the rest, with brackets making the grouping explicit
an interpretation assigns true or false to every variable, and the formula then has one truth value under it

The five connectives

NOT p: negation, true exactly when p is false
p AND q: conjunction, true only when both are true
p OR q: disjunction, true when at least one is true, so it is the inclusive or
p implies q: false only when p is true and q is false, true in every other case including when p is false
p equivalent q: true when both sides carry the same truth value

Page 1 of 4. The full sheet, all 4 pages, opens free in the app.

What this Propositional Logic and Hardware Implementation sheet covers

A proposition is a sentence with a truth value
The five connectives
NOT p
p AND q
p OR q
p implies q
p equivalent q
Three words the question will use about a formula
Identities worth knowing by sight
De Morgan, first
De Morgan, second
implication rewritten
double negation
distributive
Building a truth table without missing a row
The same logic, built in hardware
Adding one column of two binary numbers
Traps that cost marks
Tricks that save time
