A 5-page visual revision sheet for Electromagnetic Waves and Communication System, written for Class 11 Maharashtra HSC Physics. Formulas, diagrams and the traps that cost marks, laid out to be read the night before rather than the term before. Free, and it opens inside CapCompass.
Page 1 as PDF
Electromagnetic Waves and Communication System in one look
the spectrum, propagation, and the elements of a communication link
What an EM wave is
- Maxwell's equations link E and B: Gauss's laws for E and for B
- Faraday: a changing B induces an emf; Ampere-Maxwell: a current or changing E makes B
- charge at rest: only a steady E; steady speed: a steady B too; still no wave
- an accelerated charge radiates: oscillating E makes oscillating B, which regenerates E
- the wave has the frequency of the charge's oscillation; its energy comes from the source
Characteristics of EM waves
- needs no medium: it crosses vacuum
- E, B and the propagation direction are mutually perpendicular, so EM waves are transverse
- E and B oscillate in phase: they peak together
- obey superposition; carry no charge, so E and B fields don't deflect them
Speed and the E-B ratio
- speed in free space
c = frac1√μ_0ε_0 = 3×10^8 m s^-1 - speed in a medium
v_m = frac1√με - ratio of amplitudes
E_0/B_0 = c - intensity
I ∝ E_0^2 ∝ B_0^2 - frequency and wavelength
c = fλ
