Page 1 as PDF
Motion in a Plane in one look
two axes now, resolve first, then it's two straight lines
Displacement vs path length
Displacement
- a vector, the change in position vector, s = x_2 - x_1
- depends only on where you started and where you finished
- can be zero even after a long journey, as it is for one full circle
Path length
- a scalar, the actual distance covered along the way
- never decreases, and never smaller than the magnitude of the displacement
- for one full circle it is the whole circumference
Velocity and acceleration, average and instantaneous
- average velocity = displacement/time interval, average speed = path length/time interval
- instantaneous velocity, the limit as the interval shrinks to zero: v = dx/dt
- that's the slope of the x-t tangent
- instantaneous speed equals the magnitude of instantaneous velocity: over a vanishing interval, path = displacement
- acceleration a = dv/dt = d^2x/dt^2, the slope of the v-t tangent
- average and instantaneous values coincide for uniform motion, not for non-uniform
Equations of motion for uniform acceleration
- velocity after time t
v = u + at - displacement
s = ut + 1/2at^2 - velocity against displacement
v^2 = u^2 + 2as - from the average velocity
s = u+v/2 t
Page 1 of 6. The full sheet, all 6 pages, opens free in the app.
What this Motion in a Plane sheet covers
- rectilinear motion
- Displacement vs path length
- Displacement
- Path length
- Velocity and acceleration, average and instantaneous
- Equations of motion for uniform acceleration
- velocity after time t
- velocity against displacement
- from the average velocity
- Reading a motion graph
- Free fall
- Adding two velocities
- triangle law: B from the head of A, R closes it
- its size, θ between A and B
- its direction from A
- relative motion
- Relative velocity
- Rain and the umbrella
- Boat and wind problems
- Closest approach of two movers
- separation d, angle φ between the joining line and v_rel
- reached after
- Motion in two dimensions
- position, a vector
- velocity
- acceleration
- size and direction
- equations of motion, vector form
- along x
- along y
- projectile
- Projectile motion, the big idea
- Time, height, range
- time to reach the top
- time of flight
- maximum height
- horizontal range
- trajectory, t eliminated
- Special angles of projection
- Velocity of a projectile at any instant
- horizontal component, fixed
- vertical component
- speed at time t
- direction at time t
- Launched horizontally from a height
- falls for
- lands ahead by
- hits the ground at angle
- Projectile on an incline
- incline at β, launch at θ from the horizontal
- range along the slope
- max range up the incline when
- Angular quantities: θ, ω, α
- angle swept at the centre, cutting an arc s
- angular velocity, rad/s
- angular acceleration, rad/s^2
- linear from angular
- circular motion
- Uniform circular motion
- Why a points at the centre
- Centripetal acceleration and force
- acceleration towards the centre
- in terms of ω
- force needed
- Speeding up on a circle
- tangential part, along v
- centripetal part, to the centre
- total acceleration
- angle β between a and v
- Conical pendulum
- vertical balance
- horizontal, the centripetal part
- period
- frequency
- Symbols and units
- Traps that cost marks
- Tricks that save time
