Alternating Current in one look
the source keeps flipping, and every element answers it differently
- AC source: voltage reverses every half cycle
- Instantaneous value: current, generally out of step with voltage by phase Ο
- RMS value: the steady DC that delivers the same average power
Mean and RMS, said precisely
- average of sinΟ t over a full cycle is zero, positive and negative halves cancel exactly
- RMS squares first (always positive), averages that, then square-roots: v_rms = v_0/β2, i_rms = i_0/β2
- power and heating always use RMS values: the whole reason RMS exists
which reactance is bigger, X_L or X_C, at this frequency?
- XL > XC β circuit is inductive: current lags voltage, net reactance is positive
- XL = XC β resonance: reactances cancel, circuit behaves as pure R, current peaks
- XL < XC β circuit is capacitive: current leads voltage, net reactance is negative
AC through R, L, C alone
- current in phase with voltage, Ο = 0
- opposition is R, the same value at any frequency
- current lags voltage by 90Β°
- reactance X_L = Ο L, grows with frequency
- current leads voltage by 90Β°
- reactance X_C = 1/Ο C, shrinks with frequency
