Magnetism and Matter in one look
a bar magnet is a current loop that never lost its current
The bar magnet and its field lines
- outside the magnet the lines run N to S, inside they run S to N
- so every line is a closed loop, none starts or ends
- the tangent to a line is the direction of B there
- lines crowd together where the field is strong: near the poles
- two lines never cross
- iron filings and a compass both trace the lines
A bar magnet is a solenoid
- its field matches a solenoid's, loop for loop
- magnetic moment m: points S to N, m = nIA for n turns
- a loop is a dipole: its N face is where the current runs anticlockwise
- the atoms' own circulating charges are the tiny loops inside the bar
Cut it: no lone pole
- cut a magnet in two and you get two magnets, never two lone poles
- an isolated N or S pole has never been found
- every piece keeps its own N and S, in the same order
- poles are a picture, the real source is the moving charge
The far field of a bar magnet
- on the axis (r far greater than the length)
B_axis = μ_0/4π2m/r^3 - on the equator (same r)
B_eq = μ_0/4pim/r^3 - the two compared
B_axis = 2B_eq
Page 1 of 6. The full sheet, all 6 pages, opens free in the app.
What this Magnetism and Matter sheet covers
- The bar magnet and its field lines
- A bar magnet is a solenoid
- Cut it: no lone pole
- The far field of a bar magnet
- on the axis (r far greater than the length)
- on the equator (same r)
- the two compared
- A magnet in a uniform field
- torque, as a vector
- torque, size
- potential energy
- Special angles
- Swinging about B
- The energy well
- Gauss's law for magnetism
- flux through ANY closed surface
- Gauss's law, magnetic against electric
- Magnetic
- Electric
- The three, side by side
- Diamagnetic
- Paramagnetic
- Ferromagnetic
- Susceptibility and permeability
- B in terms of H and M
- magnetic susceptibility
- relative permeability
- Curie's law, paramagnetic materials
- Domains and hysteresis
- Choosing a ferromagnet
- Soft iron
- Steel
- Earth's magnetism
- Three elements of the Earth's field
- Resolving the Earth's field
- horizontal component
- vertical component
- back to the total
- the dip from the two
- Symbols
- Traps that cost marks
- Tricks that save time
