Dual Nature of Radiation and Matter in one look
light behaves like a particle, matter behaves like a wave: the same duality, seen from both sides
- Photon energy: a packet, not a spread-out wave
- Work function: the least energy to free an electron
- Max kinetic energy: whatever the photon leaves over
Electron emission: three ways out
- free electrons move inside a metal but cannot leave on their own
- leaving costs the work function Ļ_0 (the wall, W in the figures)
- thermionic: heat the metal, a few electrons gain enough to climb out
- field emission: a strong field thins the barrier, electrons slip through
- photoelectric: one photon gives all its energy to one electron
- a photon with less than Ļ_0 frees none: the electron falls back
How strongly heat and field matter
- thermionic current Jā T^2e^-W/kT: almost nothing until the metal is hot
- a lower work function gives far more current at the same temperature
- field emission needs no heating but a field of about 10^8 V/m
- in a hot or field-fed metal the electrons leave with little energy; a photon can give much more
Page 1 of 5. The full sheet, all 5 pages, opens free in the app.
What this Dual Nature of Radiation and Matter sheet covers
- Photon energy
- Work function
- Max kinetic energy
- Electron emission: three ways out
- How strongly heat and field matter
- The photoelectric effect, observed
- Einstein's photoelectric equation
- energy balance
- work function and threshold frequency
- stopping potential
- Brightness and the stopping potential
- What raises current vs what raises stopping potential
- Raise the intensity
- Raise the frequency
- Particle nature of light: the photon
- The photon's energy and momentum
- energy, from frequency or wavelength
- momentum
- a handy form
- Light pushes
- de Broglie waves
- wavelength of any particle of momentum p
- after acceleration through potential V, charge q
- for an electron
- de Broglie wavelength, the special forms
- Davisson and Germer
- Wave-particle duality, both directions
- Symbols
- Traps that cost marks
- Tricks that save time
