Page 1 as PDF
Oscillations in one look
one restoring force proportional to displacement, and everything else in this chapter follows from it
Periodic, oscillatory and simple harmonic
- periodic motion repeats after a fixed interval, the period T
- oscillatory motion goes back and forth about a mean position
- every oscillation is periodic, not every periodic motion oscillates (circular motion)
- along a line: linear S.H.M.; along an arc: angular S.H.M.
- frequency n = 1/T, angular frequency ω = 2π n = 2π/T
The defining condition and its equation
- restoring force, always toward the mean position
f = -kx - Newton's second law gives
ma = -kx - the differential equation of linear S.H.M.
d^2x/dt^2 + ω^2x = 0,quad ω^2=k/m
Displacement, velocity and acceleration
- displacement
x = Asin(ω t + φ) - velocity
v = dx/dt = Aωcos(ω t + φ) = ω√A^2-x^2 - acceleration
a = dv/dt = -Aω^2sin(ω t + φ) = -ω^2x
The two extremes of a swing
| mean position, x = 0 | extreme, x = ± A | |
|---|---|---|
| speed | largest, Aω | zero, for an instant |
| acceleration | zero | largest, Aω^2 |
| energy | all kinetic | all potential |
Page 1 of 7. The full sheet, all 7 pages, opens free in the app.
What this Oscillations sheet covers
- periodic motion
- simple harmonic motion
- Periodic, oscillatory and simple harmonic
- The defining condition and its equation
- restoring force, always toward the mean position
- Newton's second law gives
- the differential equation of linear S.H.M.
- Displacement, velocity and acceleration
- displacement
- velocity
- acceleration
- The two extremes of a swing
- S.H.M. as a projection of circular motion
- Period and frequency
- angular frequency, spring-mass system
- period, from acceleration per unit displacement
- frequency
- In the lab: a helical spring
- Springs in combination
- in series, same force f on each spring
- in parallel, same extension on each spring
- Reading the phase
- composition of shm
- Composition of two S.H.M.s, same period and path
- resultant amplitude
- resultant phase
- Three special cases
- Energy in S.H.M.
- Energy formulas
- kinetic energy at displacement x
- potential energy at displacement x
- total energy, any instant
- simple pendulum
- Simple pendulum, the numbers
- period
- angular frequency
- In the lab: the simple pendulum
- In a lift; a physical pendulum
- in a lift, speeding up / down
- a rigid body, G a distance d below the pivot
- Conical pendulum
- Angular S.H.M.
- restoring torque, angular displacement θ
- differential equation, moment of inertia I
- Damped oscillations
- Damped oscillation, the equation
- equation of motion, spring constant k
- the damped angular frequency
- resonance
- Free oscillations, forced oscillations and resonance
- Traps that cost marks
- Tricks that save time
